Lonsdor K518 Program Ford Escort 2017 All Keys Lost

Lonsdor K518 auto key programmer has successfully programmed smart keys on a Ford Escort year 2017 under all keys lost situation.

ford-escort-2017

Key information:

Original key: 3-button folding key

Remote frequency: 433MHz

Chip type: 49 chip

Device to program: Lonsdor K518 key programmer

Requirement: At least 2 keys are required to be programmed

k518-ford-escort-1

Procedure:

Connect K518 host with vehicle via OBD socket

Turn ignition switch to ON position

Select Ford->Escort->Program Key->All keys lost

k518-ford-escort-2

k518-ford-escort-3

k518-ford-escort-4

k518-ford-escort-5

Turn iginition off

k518-ford-escort-6

At least 2 keys are required to be programmed

k518-ford-escort-7

Insert first key and turn on ignition

k518-ford-escort-8

k518-ford-escort-9

Turn ignition off and remove key

k518-ford-escort-10

Insert second key and turn on ignition

k518-ford-escort-11

Lonsdor K518ISE identified number of keys programmed: 2

k518-ford-escort-12

Program success

k518-ford-escort-13

Disconnect Lonsdor k518 programmer.

Test the new keys.
